Edna 2 has a single main LED plus low power side LED. The main high power LED (with forward bias wide angle flood optic) offers 4 power settings well suited to caving. Edna also has a separate side LED (white smd LED) for maximum run time. Edna features battery charge level indication (white smd LED blinks 1-5 times when exiting moon mode, visible without removing helmet).



Edna 2 is operated by a sealed switch on the top rear of the lamp body. The easy push switch can be operated in two distinct ways, <short push> or <long push> (push and hold).  The four available main LED light settings are in a continuous forward loop, 1 to 4, and off. Each of the settings can be selected in turn, by pressing the switch <short push>.  The four main Edna light settings are (based on single 3500 mAh battery pack);



low    (70 lumen, 30 hours) ... smaller cave passages

med   (170 lumen, 10 hours) ... general progression around cave

high   (320 lumen, 5 hours) ... progression in large passages

max   (1000 lumen, 1 hour) ... having a good look around !!



In order to avoid cycling through subsequent light settings, Edna 2 can be turned off from any setting with a long switch press <long push>. When lamp is off, there is effectively zero drain on battery. A <long push> from off provides camp setting (5 lumen, 200+ hours).



For full information on operation, fitting and proper use, see Edna 2 Operation Guide FE2.1.1 (Pdf)
